ESD Tiles
110 INR
Product Details:
- Product Type ESD tiles
- Material PVC with conductive components
- Application Electrostatic discharge protection and flooring
- Surface Resistance 10^4 to 10^6 ohms
- Usage Flooring for ESD-sensitive environments
- Testing Function Surface resistance testing
- Trigger Mode Passive
- Click to View more
X
ESD Tiles Price And Quantity
- 1000 Square Foot
- 110 INR
- 75.00 - 145.00 INR
ESD Tiles Product Specifications
- Surface conductivity measurement
- Flooring for ESD-sensitive environments
- Typically 5 years (manufacturer-specific)
- Electrostatic discharge protection and flooring
- PVC with conductive components
- Approx 5kg per tile
- 10^4 to 10^6 ohms
- 600mm x 600mm
- Surface resistance testing
- Standard tile dimensions (e.g. 600mm x 600mm x 3mm approximation)
- Passive
- Grey and white
- ESD tiles
Product Description
Available in both conductive and static dissipative properties, these ESD tiles are compressed ESD Vinyl based tiles.
The manufacturing technology ensures that the tiles remain conductive permanently and also incorporate very good
mechanical properties, abrasion resistance, indentation resistance and chemical resistance. The ESD tiles have a
low content of Plasticisers.
Size : 600 mm x 600 mm
Thickness : 2 MM
Color : White Granite finish
Surface Resistivity : 106 to 108 ohms / Sq ,
Volume Resistivity : 106 to 108 ohms / Sq
Rate of Decay : < 0.02 Seconds,
Hardness : < 85 shore
D Static Generation : < 100 Volts ,
Flammability : Self Extinguishing
