ESD Tiles

Product Description

Available in both conductive and static dissipative properties, these ESD tiles are compressed ESD Vinyl based tiles.

The manufacturing technology ensures that the tiles remain conductive permanently and also incorporate very good

mechanical properties, abrasion resistance, indentation resistance and chemical resistance. The ESD tiles have a

low content of Plasticisers.

Size : 600 mm x 600 mm

Thickness : 2 MM

Color : White Granite finish

Surface Resistivity : 10⁶ to 10⁸ ohms / Sq ,

Volume Resistivity : 10⁶ to 10⁸ ohms / Sq

Rate of Decay : < 0.02 Seconds,

Hardness : < 85 shore

D Static Generation : < 100 Volts ,

Flammability : Self Extinguishing
